Any three-phase induction motor must be connected to a three-phase AC power supply with rated voltage and load for regular operation. Once started, the motor will continue to run even if one of the three-phase power lines is interrupted. The current loss on one of the power lines is called single-phase operation.

Ships are equipped with hundreds of electric motors to drive various pumps, machines, and systems. Critical equipment, such as steering systems, prime movers, generators, and boilers, is equipped with three-phase motors driving main or auxiliary systems.

440-volt three-phase motors are typically standard squirrel-cage induction motors designed for 440-volt, 60-Hz three-phase AC. Small-power motors with a power rating of 0.4 kW or less are mainly used for lighting and other low-power systems and are typically 220V, 60Hz single-phase motors.

Causes of Single-Phase Operation

Single-phase operation is an electrical fault related to the induction motor power supply. When one of the three phases of a three-phase motor's circuit breaks, single-phase operation occurs, causing the remaining circuits to carry excessive current. This typically happens under the following conditions:

• One or more of the three spare fuses blow (or the fuse itself if it's a line fuse).
• An open circuit exists in the motor's power supply circuit.
• Improper adjustment or error of any motor protection device can lead to single-phase operation.
• Scaling or oxidation can occur on the contacts if they are not regularly maintained, resulting in single-phase operation.
• Damaged or broken motor relay contacts.
• Damaged motor circuit wiring.
• Power system failure.
• Short circuit in one phase of the motor in a star or delta connection.
• Blown power supply or transformer fuse.

Impact of Single-Phase Operation

As mentioned earlier, a three-phase motor is an AC motor designed for a three-phase power supply. Both types of motors have similar structures, containing a stator and a rotor. Single-phase motors do not have a rotating magnetic field; instead, they use a 180-degree reverse magnetic field. Single-phase motors typically cannot self-start. Therefore, additional equipment is required, such as replacing the starting coil or capacitor. Single-phase operation of a three-phase induction motor can cause the following effects:

• If the motor stops running, it cannot start because single-phase motors cannot self-start (as mentioned above), and the three-phase motor's built-in overheat protection system will also prevent it from starting.
• If a single-phase operation fault occurs while the motor is running, the motor will continue to run due to the torque generated by the remaining two phases (depending on load demand) (unless equipped with an additional safety disconnect system).
• Because the remaining two phases must carry the extra load of the faulty phase, they will overheat, potentially causing serious winding damage.
• Single-phase operation can cause the current to reach 2.4 times the average current of the remaining two phases.
